Cisco 7600 Cisco 1-Port 10GE LAN-PHY Shared Port Adapter SPA-1X10GE-L-V2
SPA-1X10GE-L-V2 Specifications | |
| Feature | Description |
| Product Compatibility | • Cisco Catalyst 6500 Series Switches • Cisco 7600 Series Routers • Cisco 12000 Series Routers • Cisco XR 12000 Series Routers • Cisco ASR 1000 Series Router • Cisco CRS Carrier Routing System • Cisco 10000 Series Router |
| Port Density per SPA | One 10 Gigabit Ethernet port |
| Physical Interface | 10-Gbps XFP optics |
| LED Indicators | SPA status-Bicolor green and amber LEDs encode the SPA status as follows: • LED off-SPA is powered off • LED amber-SPA is powered on and initializing • LED green-SPA is powered on and operational In addition to the status LED, the SPAs also have a bicolor LED dedicated to each port to indicate port status. The green and amber LEDs encode the port status as follows: • LED off-Port is not activated by software • LED amber-Port is activated by software, but there is a problem with the Ethernet link • LED green-Port is activated by software, and there is a valid Ethernet link |
| Features and Functions | • Full-duplex operation • 802.1Q VLAN termination • 802.1ad QinQ termination (stacked VLAN processing) • Jumbo frames support (9188 bytes) • Support for command-line interface (CLI)-controlled online insertion and removal (OIR) • 802.3x flow control • Bridge protocol data unit (BPDU), Cisco Discovery Protocoland VLAN Trunking Protocol (VTP) filtering • Layer 2 Protocol (BPDU, Cisco Discovery Protocol, and VTP) Tunneling • Layer 2 access list (MAC address-based filtering) • Up to 8000 VLANs per SPA and subject to a limit of 4000 VLANs per port for 802.1q • Up to 5000 MAC accounting entries per SPA (source MAC accounting on the ingress, and destination MAC accounting on the egress) • Up to 2000 MAC address entries for destination MAC address filtering per SPA, and up to 1000 MAC ad • Per-port byte and packet counters for policy drops; oversubscription drops; cyclic-redundancy-check (CRC) error drops; packet sizes; and unicast, multicast, and broadcast packets • Per-VLAN byte and packet counters for policy drops; oversubscription drops; and unicast, multicast, and broadcast packets • Per-port byte counters for good bytes and dropped bytes Other software features supported: • Ethernet over Multiprotocol Label Switching (EoMPLS) • QoS • Hot Standby Router Protocol (HSRP) • Virtual Router Redundancy Protocol (VRRP) |
