HPE Aruba 2930F 48G 4SFP+ Switch – High-Performance 48-Port Gigabit + 10G Uplink

Description

HPE Aruba 2930F 48G 4SFP+ Switch – High-Performance 48-Port Gigabit + 10G Uplink

HPE Aruba 2930F 48G 4SFP+ Switch is a high-performance access switch designed for modern digital workplaces. Supporting 48 Gigabit Ethernet ports and 4 SFP+ 10G uplinks, this switch enables seamless wired and wireless integration for mobile-optimized environments. Ideal for enterprise and campus networks, it delivers low-latency, high-throughput performance for growing network demands.

---

Key Features

High-Density Connectivity

• 48x 10/100/1000 RJ-45 ports with autosensing for fast and reliable connectivity

• 4x 10G/1G SFP+ uplink slots for high-speed backbone connections

• PHY-less design reduces complexity while improving efficiency

Performance & Throughput

• Switching capacity: 176 Gbps

• Forwarding rate: Up to 112 Mpps

• Low latency: <3.8 µs at 1 Gbps, <1.6 µs at 10 Gbps

• Dual-core ARM Cortex A9 @ 1016 MHz with 1 GB DDR3 SDRAM

• Packet buffer: 12.38 MB (4.5 MB ingress / 7.875 MB egress)

• Storage: 4 GB eMMC

Power & Efficiency

• Power consumption: 46.6 W (maximum)

• Heat dissipation: 157.2 BTU/hr (165.8 kJ/hr)

• Input voltage: 100–127 / 200–240 VAC

Management & Security

• HPE Aruba AirWave: Centralized network management

• Intelligent Management Center (IMC)

• CLI, web browser GUI, SNMP, Telnet, RMON1, FTP

• Out-of-band management via RS-232C or micro USB

• Configuration menu simplifies deployment and monitoring

Physical & Environmental Specs

• Weight: 3.1 kg (6.83 lb)

• Dimensions: 4.39 × 44.25 × 24.63 cm (1.73 × 17.42 × 9.7 in)

• Compact design fits standard 19-inch racks

---

Benefits

• Optimized for mobile users: Integrated wired and wireless approach

• High reliability: Low-latency switching ensures consistent performance

• Scalable network: Supports high-density deployments with 48 ports and 10G uplinks

• Centralized management: Simplified network administration with AirWave and IMC

• Energy-efficient design: Low power consumption and optimized heat dissipation

---

Ideal Use Cases

• Enterprise campus networks requiring high-density Gigabit access

• Digital workplaces supporting mobile users and BYOD environments

• Branch offices needing low-latency 10G uplink connectivity

• Networks requiring robust management and monitoring tools

---

Technical Specifications
