TerraMaster D5 Hybrid – 5-Bay Hybrid Direct-Attached Storage Enclosure

TerraMaster D5 Hybrid 5-Bay Hybrid Disk Enclosure with USB 3.2 Gen2

The TerraMaster D5 Hybrid is the industry’s first hybrid direct-attached storage (DAS) enclosure, designed to combine high-capacity SATA HDD storage with high-performance NVMe SSD speeds in one compact and reliable device. It supports 2 SATA HDD/SSD bays and 3 M.2 2280 NVMe SSD slots, delivering an ideal storage solution for professionals who require both speed and large capacity.

By separating hot data on NVMe SSDs and cold data on traditional hard drives, the TerraMaster D5 Hybrid improves workflow efficiency while keeping storage costs under control. When used with TerraMaster TPC Backupper, users can schedule automatic backups, ensuring continuous protection of critical data.

---

Key Features

Innovative Hybrid Storage Architecture

• First hybrid DAS with 2 SATA + 3 NVMe bays

• Optimized for high-speed access and large-capacity storage

• Ideal for creative professionals, studios, and business users

Automatic Backup with TPC Backupper

• Free Windows backup software included

• Supports scheduled, incremental, and differential backups

• Backs up folders and partitions automatically

• Compatible with Windows 8, 8.1, 10, and 11

High-Speed 10Gbps Data Transfer

• USB 3.2 Gen2 Type-C interface with up to 10Gbps bandwidth

• NVMe SSD read speeds up to 980MB/s

• SATA SSD RAID 0 speeds up to 960MB/s

• HDD RAID 0 speeds up to 565MB/s

Wide System Compatibility

• USB Type-C interface compatible with USB 3.0, 3.1, 3.2, USB4

• Supports Thunderbolt 3 and Thunderbolt 4

• Compatible with Windows 7 or later, macOS 10.6 or later, and Linux Ubuntu 16, 18, and 20

---

Compact Design with Large Storage Capacity

The TerraMaster D5 Hybrid supports up to five drives in a compact enclosure:

• Up to 22TB per SATA HDD

• Up to 8TB per NVMe M.2 SSD

• Maximum raw capacity of 68TB

Note: Incompatible hard drives may cause performance or recognition issues. Always verify compatibility using the official TerraMaster hard disk compatibility list before purchasing.

---

2+3 Hybrid Array Mode

• SATA Bays (2):

  • RAID 0

  • RAID 1

  • JBOD

  • Single Disk

• NVMe Bays (3):

  • Single Disk mode only

For best performance, frequently accessed data should be stored on NVMe SSDs, while SATA HDDs are recommended for backup and archival storage.

---

Tool-Free Drive Installation

Easy SATA Drive Replacement

• Tool-free drive trays

• Push-Lock design prevents accidental disconnection

• Drive installation in less than 10 seconds

Simple M.2 NVMe SSD Installation

• Side sliding cover for quick access

• Hand-tightened screws included

• SSD installation in approximately 5 seconds

---

Intelligent Cooling, Low Noise, and Power Protection

• Intelligent temperature-controlled cooling fan

• Dedicated airflow channel for NVMe SSDs

• Standby noise level as low as 19dB(A)

• Advanced power protection to prevent damage from incorrect power input

---

Power-On Recovery Function

The TerraMaster D5 Hybrid features power-on recovery memory. After an abnormal power outage, the device automatically restarts when power is restored, making it suitable for server environments, NAS setups, and unattended operation.

---

Technical Specifications

Storage

• Disk Bays:

  • 2 × 3.5″ / 2.5″ SATA HDD or SSD

  • 3 × M.2 2280 NVMe (PCIe 3.0 / 4.0 / 5.0)

• Maximum Raw Capacity: 68TB

• Supported File Systems: NTFS, APFS, macOS, FAT32, exFAT, EXT4

• RAID Support (SATA only): Single Disk, JBOD, RAID 0, RAID 1

• Hardware RAID: Yes

• HDD Sleep Mode: Yes

• Auto RAID Rebuild: Yes

---

Interface and Performance

• USB Interface: USB 3.2 Gen2 Type-C (10Gbps)

• Maximum Read Speed:

  • HDD RAID 0: 565MB/s

  • SSD RAID 0: 960MB/s

  • NVMe SSD: 980MB/s

• Maximum Write Speed:

  • HDD RAID 0: 524MB/s

  • SSD RAID 0: 956MB/s

  • NVMe SSD: 880MB/s

---

Physical and Power

• Dimensions: 222 × 119 × 154 mm

• Net Weight: 1.3 kg

• Power Supply: 40W

• Power Consumption:

  • 30W under full load

  • 8.1W in hibernation

---

Environmental Specifications

• Operating Temperature: 0°C to 40°C

• Storage Temperature: -20°C to 60°C

• Relative Humidity: 5% to 95% RH

---

System Compatibility and Certifications

• Supported OS: Windows, macOS, Linux

• Certifications: CE, FCC, CCC, KC

• Warranty: 2 Years

• RoHS Compliant

---

Package Contents

• TerraMaster D5 Hybrid Enclosure

• USB-C to USB-C Cable (10Gbps, 0.8m)

• Power Adapter

• Quick Installation Guide

• Screws

• Limited Warranty Card
